Product Details:
|
| Product Name: | Cleanroom Pre-air Filter | Keyword: | Air Filter |
|---|---|---|---|
| Style: | Pre-Filter | Material: | Synthetic Fiber With Alumium Frame |
| Function: | Air Filtration | Remark: | Change Every 3 Months |
| Highlight: | 1600m3/h Cleanroom Air Filter,G3 G4 Cleanroom Air Filter,1600m3/h Pre Air Filter |
||
Cleanroom Pre-air filter is made from a sheet of polyester, paper, or cotton folded into pleats to increase the entire surface area. This allows the filter to trap more airborne particles such as dust, dirt, and hair (from pets and humans), which could otherwise damage your furnace's blower fan and clog the AC coils. As a secondary benefit, a pleated filter will improve the indoor air quality of your home.
Pleated air filters are popular for 2 main reasons:
1. Sturdier and more efficient than the conventional fiberglass filters
2. Cost less than the super-efficient electrostatic filters.
3. Welded wire mesh adopts surface anti-rust treatment, which can fix the linear folding structure well.
Pleated air filters are one of the most common filters for home heating and cooling systems.
Material Composition And Operating Conditions
| Material | Synthetic Fiber With Aluminum Frame |
| Filtration Efficiency | G1, G2, G3, G4 |
| Permissible max relative temperature | 80℃ |
| Permissible max relative humidity | 100% |
Parameters
| Size (mm) |
Rated Air Rate (m³/h) |
Filter Area (㎡) |
Initial Resistance (Pa) |
Final Resistance (Pa) |
Efficiency |
| 287*592*46 | 1600 | 0.97 | ≤25 | 100-200 | G1 |
| ≤30 | 100-200 | G2 | |||
| ≤40 | 100-200 | G3 | |||
| ≤45 | 150-250 | G4 | |||
| 592*592*46 | 2600 | 0.44 | ≤25 | 100-200 | G1 |
| ≤30 | 100-200 | G2 | |||
| ≤40 | 100-200 | G3 | |||
| ≤45 | 150-250 | G4 |
Application
Cleanroom Pre-air filter in air-conditioning system, pre-filtration in multistage filtrationsystem, air filtration in general acid base organic solvent.
