Product Details:
|
| Keyword: | Air Filter | Function: | Air Purification |
|---|---|---|---|
| Efficiency: | Medium | Type: | |
| Material: | Synthetic Bag With Alumium Frame | Remark: | Change Every 6 Months |
| Highlight: | 2.65m2 Area Synthetic Bag Filter,2.65m2 Area Pocket Bag Air Filters,EN779 Pocket Bag Air Filters |
||
GCC Synthetic Bag Filters now utilizes an internal stitch design engineered to withstand demanding applications. Years of development and the highest quality raw materials available are combined to create manufacturing air bag filters unmatched in performance and value. GCC Bag Filters extended surface bag filter was developed to provide dependable performance in commercial and industrial applications.
Synthetic Bag Filters not only only reduce up to 98% of allergens and microscopic particles for both homes and businesses but effectively eliminate allergies and sinus irritation that can cause watery eyes, itchy throat, coughing, and sneezing. We highly recommend filters for any asthmatics or respiratory sufferers who requirer premium indoor quality in the their home or office. Will attract and capture the small, allergy-aggravating micro-particles that can cause your family discomfort and collect more than 90-Percent of ALL microns of contaminants. Particles in indoor air are measured in microns, which are 1/1000 of a millimeter. Because of this high filtration and air flow restriction, heating and air conditioner systems should be checked to make sure they can handle filters rated MERV 14 and above.
GCC Synthetic Bag Filters meets the Green Building Council's latest LEED (Leadership in Energy and Environmental Design) Indoor Air Quality Requirements for optimal indoor quality. These filters meet and/or exceed standard requirements for American Lung Association® Health House® and utilizes electrostatically charged, 100% synthetic media which offers significantly higher particulate efficiency than regular poly/cotton media pleated filters, with little change in static pressure.
Synthetic Bag Filters Characteristic
1. The synthetic fiber media can hold a abundant dust with Ultrasonic sew bag,
2. The efficiency stable in the whole life-span,
3. Optimized V-collector structure has low resistance with long life-span,
4. The frame can be plastic, AL,GL for your choose,
5. The average efficiency is 85-90% (ASHAE50 1-1993),
6. Filtration efficiency grade rang from .G3.85%@2.0um, G490%@2.0um .(EN799).
Synthetic Bag Filters Material Composition And Operating Conditions
| Material | Fiberglass Paper With Aluminum Frame |
| Filter Bag Type | Since The Bag Sewing |
| Filtration Efficiency | F5,F6,F7,F8(EN779) |
| Permissible Max Relative Temperature | 150℃ |
| Permissible Max Relative Humidity | 100% |
Synthetic Bag Filters Parameters
|
Size (mm) |
Number of Bags |
Air Volume (m³/h) |
Filter Area (㎡) |
Initial Resistance (Pa) |
Initial Resistance (Pa) |
Efficiency |
| 287*592*381 | 3 | 1000 | 1.58 | <50 | 250-300 | F5 |
| <65 | 250-300 | F6 | ||||
| <80 | 300-400 | F7 | ||||
| <100 | 300-400 | F8 | ||||
| 490*592*381 | 5 | 1700 | 2.65 | <50 | 250-300 | F5 |
| <65 | 250-300 | F6 | ||||
| <80 | 300-400 | F7 | ||||
| <100 | 300-400 | F8 | ||||
| 592*592*381 | 6 | 2050 | 3.18 | <50 | 250-300 | F5 |
| <65 | 250-300 | F6 | ||||
| <80 | 300-400 | F7 | ||||
| <100 | 300-400 | F8 |
Synthetic Bag Filters Application
Suitable for commercial and industrial applications, especially home or office.
