Product Details:
|
| Keyword: | Fresh Air Cabinet | Application: | Laboratory, Operating Room, Biopharmaceutical, LED Lights, Circuit Boards, Microelectronics, Medical Industry, Food Processing And Other Clean Fresh Air Demanding Work Environment. |
|---|---|---|---|
| Warranty: | 1 Year | Inspection Video: | Provided |
| After-Sales Service: | Provided | Remark: | Size Can Be Customized |
| Highlight: | G1 H3 Filtration Fresh Air Cabinet,550w Fresh Air Cabinet,550w fresh air box |
||
The Fresh Air Cabinet is also known as the fresh air booster box. It is mainly used for fresh air ventilation in various workshops. Its function is to increase indoor fresh air and speed up air circulation. The air volume required for the Fresh Air Cabinet depends on the size of the field used, and the air outlet of the Fresh Air Cabinet. The detection height can reach the clean class 100.
Because of its flexible structure, low noise, stable operation, adjustable wind pressure and long service life, the 100 is widely used in the ventilation system of civil buildings, and can also be applied to the fire pressure of building construction. It is a very effective air purification equipment for air supply and purification of air conditioners.
Use the fresh air cabinet and fresh air system to ensure the indoor fresh air volume and breathe fresh and clean air. It is a very effective air purification equipment.
Fresh Air Cabinet Features
1. Supply jet blow air of air throw up to 40M to conditioning open space,
2. Ultra slim ceiling mounted AHU (only 490mm height up to 2000CMH), save installation space,
3. Plug and play concept for easy installation and commissioning,
4. No ductwork, save installation cost and time,
5. Large air volume (20000CMH) and cooling capacity (200kW),
6. Fixed points jet distribution, max distribution distance more than 40M,
7. Operation efficiency and energy saving,
8. Outstanding reliability and performance.
| Item | GCC-FAC-01 | GCC-FAC-02 | GCC-FAC-013 | GCC-FAC-04 | GCC-FAC-05 |
| Material | Stainless Steel or Steel | ||||
| Size | 800*800*1200mm | 800*800*1200mm | 1450*800*1350mm | 1450*800*1500mm | 1450*800*1700mm |
| Air Flow | 1000~2000m/s | 2000~3000m/s | 3000~4000m/s | 4000~5000m/s | 5000~6000m/s |
| Power | 550w | 800w | 1100w | 2200w | 2200w |
| Voltage | 380v/50hz | ||||
| Noise | ≤67 | ||||
| Filtration Efficiency |
G1+H3 |
||||
Fresh Air Cabinet Applications
Suitable for commercial and industrial large open space, production line, sport center, airport terminal, train station, factory workshop and shopping mall.
